Designed Around Life Safety and Protection

Reliable everyday safety through engineered wooden door systems designed to help contain fire, protect occupants, and support code compliance

Door solutions play a vital role in helping protect interior environments in the event of fire.

This fire-rated solution is developed as a complete safety-oriented system, designed to help contain flames and smoke, support safe evacuation, and maintain structural integrity under demanding conditions. Various ratings are available to meet specific project requirements and compliance standards.

Our doors are engineered using tested fire-rated construction principles and high-performance materials to deliver dependable protection when it matters most, while preserving architectural continuity and design intent.

Positioned as a responsible long-term investment, our fire-rated door solutions combine compliance, durability, and performance, supporting a wide range of commercial, institutional, and high-traffic applications.

BROWSE OUR PRODUCTS

Maximum Dimensions

	Agrifibre	SCL / LSL		Particle	Mineral Core
	45 min	20 min	45 min	20 min	45 min	60 min	90 min
Max Single	4-0” x 10-0”	4-0” x 9-0”	4-0” x 8-0”	4-0” x 9-0”	4-0” x 9-0”	4-0” x 9-0”	4-0” x 9-0”
Max Pair Surface Vertical Rod	8-0” x 8-0”	8-0” x 9-0”	8-0” x 8-0”	8-0” x 9-0”	8-0” x 9-0”	8-0” x 9-0”	8-0” x 9-0”
Surface Vertical Rod – Less Bottom Rod	6-0” x 7-0”	8-0” x 9-0”	n/a	8-0” x 9-0”	8-0” x 9-0”	8-0” x 9-0”	8-0” x 9-0”
Concealed Vertical Rod	8-0” x 8-0”	8-0” x 9-0”	8-0” x 8-0”	8-0” x 9-0”	8-0” x 9-0”	8-0” x 9-0”	8-0” x 9-0”
Concealed Vertical Rod – Less Bottom Rod	n/a	8-0” x 9-0”	n/a	8-0” x 9-0”	8-0” x 9-0”	8-0” x 9-0”	8-0” x 9-0”
3 Points Latch	8-0” x 8-0”	8-0” x 9-0”	8-0” x 8-0”	8-0” x 9-0”	8-0” x 9-0”	8-0” x 9-0”	8-0” x 9-0”
Max Pair Double Egress SVR	8-0” x 8-0”	8-0” x 8-0”	8-0” x 8-0”	8-0” x 8-0”	8-0” x 9-0”	8-0” x 8-0”	8-0” x 8-0”
Surface Vertical Rod – Less Bottom Rod	n/a	n/a	n/a	n/a	8-0” x 9-0”	8-0” x 8-0”	8-0” x 8-0”
Concealed Vertical Rod	8-0” x 8-0”	8-0” x 8-0”	n/a	8-0” x 8-0”	8-0” x 9-0”	8-0” x 8-0”	8-0” x 8-0”
Concealed Vertical Rod – Less Bottom Rod	n/a	n/a	n/a	n/a	8-0” x 9-0”	8-0” x 8-0”	8-0” x 8-0”
Max Lite	31 x 54 (1296 sq in)	34 x 74 (2524 sq in)	30 x 36 (1080 sq in)	34 x 74 (2524 sq in)	30 x 70 (2176 sq in) Metal kit	24 x 40 (960 sq in) Metal kit	24 x 40 (960 sq in) Metal kit
Max Louver	24 x 36 (864 sq in)	n/a	24 x 24 (576 sq in)	n/a	24 x 36 (864 sq in)	24 x 36 (864 sq in)	24 x 36 (864 sq in)
Transom	Door and transom 4-0” x 10-0”	n/a	n/a	n/a	Door and transom 4-0” x 9-0”	48 x 40 4-0” x 9-0”	48 x 40 (3) 4-0” x 9-0”
Dutch Door	4-0” x 8-0”	n/a	n/a	n/a	n/a	n/a	n/a
